Extra information

System documentation: [InFlow API Reference] InFlow Connector Package Documentation

​

Setting up HTTP Client InFlow

​

Steps

• In Alumio Dashboard, go to Clients > HTTPS Client. Create a new HTTP Client and select InFlow HTTP Client as the prototype of the HTTP Client.
• Fill in the Base URI, Api Key, and Accept Versioning Parameter (Default 2024-03-12, feel free to change the version).
• Save the Client for use later.

​

Subscribing to Entities from InFlow

​

Steps

• Go to Connections -> Incoming and create a new incoming configuration and select InFlow Subscriber as the subscriber.
• Select the entity you want to subscribe from InFlow .
• Add any request parameters needed to subscribe to the entity (optional).
• You can optionally add a transformer to transform the request parameters into something you need.
• Select the InFlow HTTP Client to use.

​

General Concept

We follow InFlow documentation on building this connector so you can easily use the connector based on InFlow API Reference. Method It’s the Method you want to subscribe from InFlow. Based on the Method, the Entity will change. Please refer to the entities in Management APIs from InFlow API Reference page. Entity It’s the entity you want to subscribe from InFlow . Please refer to the entities in Management APIs from InFlow API Reference page. Request Parameters These are the parameters you can provide to get the needed entity based on InFlow API Reference. Please look at the example below on how to fill the Request Parameters field when subscribing Get a category. That’s why we need to define the categoryId property inside the path property in the Request Parameters field. The properties inside query parameters will be parsed as query parameters. Here is the final URL that will be called when using such Request Parameters field on Get a category. /companyId/categories/abc123 Input Transformer Any transformer’s set here will be executed after the Request Parameters are loaded. So, you basically can add any transformer to provide and transform the request parameters into anything you need either as path parameters and/or as query parameters of an entity. HTTP Client It’s the HTTP Client configuration or prototype you will use to access InFlow .

​

Publishing Entity to InFlow

​

Steps

• Go to Connections -> Outgoing, create a new outgoing configuration, and select InFlow Publisher as the publisher.
• Select the action that you want the publisher to do with the data.
• Select the InFlow entity you want the data to be published.
• You can optionally add any query parameters to the request.
• You can also optionally add any transformers to transform the data into anything you need before submitting it to InFlow .
• Select the HTTP Client to use.

​

General Concept

Like the subscriber, the publisher has similar methods on how to use it. The difference is the payload that will be submitted by the publisher originating from the data (from routes, from transformers in outgoing configuration), though you can also add or modify payload using the Request Transformer. Method Currently, we support Put (HTTP PUT method), and Delete (HTTP DELETE method). Entity We support publishing to most InFlow endpoints. Please refer to the entities in Management APIs from the InFlow API Reference page. Based on the documentation, some endpoints may need one or more path parameters. For endpoints that require an object as the request payload, please look at the example below. For example, we want to Create product. Please select “Put” as the action and “Insert or update product” as the entity of the publisher. You can put the payload you want to send to InFlow into the payload property in the data. Alumio will send an API request to InFlow with URL /products HTTP Client It’s the HTTP Client configuration or prototype you will use to access InFlow .
